The Dolle SW26 Timber Attic Access Kit is ideal for those looking for a simple attic access solution to enable safe access to the loft. measuring 118 × 58cm with an insulated draught-proof hatch, the Dolle SW26 is supplied as a semi-assembled unit, making installation easier. Ideal choice for individuals seeking a basic but sturdy solution to accessing the attic. Suitable for floor to ceiling heights up to 2.87m.
Features
Solid spruce wooden ladder
Rubber draught excluder
Handrail to aid safe climbing
Slip-resistant treads and feet
Available in three different casting sizes 115 x 57cm, 120 x 60cm & 120 x 70cm
26mm thick white-brown faced trapdoor with 20 mm insulating to reduces heat loss
U-value 1.60
Requires no arc space for clearance or storage space in the attic
Includes timber stowing pole
Optional spring clip to secure sections when deployed
Optional attic Ladder Extension Kit available to increase height to 3.33m
Tested to a huge 265kg working load
150kg load capacity
Air-tight class 4 in accordance with DIN EN 12207
Produced according to DIN EN 14975
Downloads
Dolle SW26 Wooden Attic Ladder Mounting Instructions
Dolle 22365 22375 SW26 Wooden Attic Ladder Dimensions
Notes
Load includes user, tools, materials, etc.
Guarantee against manufacture defects in workmanship or materials
Specifications
Unique Selling Point
Compact Designs,Gain access to the loft
Code
1022365-100
Size
2.87m
Style
3 Section
Number of Treads
12
Material
Wood
Performance
Domestic
Certifications
EN 14975
Handrail Included
Yes
Handrail Material
Steel
Operating Pole Included
Yes
Operating Pole Material
Wood
Separate Foot Attachment
Yes
Foot Material
Plastic
Door Included
Yes
Number of People for Installation
2
Max. Load (kg)
150 kg (23st 9lb)
Guarantee
10 Year
Dimensions
Floor To Ceiling Height (m)
2.87m
Approx. Product Weight (kg)
24.0kg
Opening Size (LxW) (m)
1.2m x 0.6m
Casing Height (m)
0.12m
Casing Length (m)
1.18m
Casing Width (m)
0.58m
Opening Arc (m)
1.58m
Ladder Width (m)
0.40m
Tread Width (m)
0.38m
Trapdoor Insulation Thickness (mm)
26mm
